LVL Description

LVL ( Laminated Veneer Lumber) is a widely used structural composite lumber product. It is produced by bonding thin wood veneers together in a large billet so that the grain of all veneers is parallel to the long direction.



The LVL lumber is sawn to desired dimensions depending on the end-use application. Because LVL is made with scarfed or lapped jointed veneers, LVL is available in lengths far beyond conventional lumber lengths. COZE LVL TIMBER max length achieve 6 meters.



LVL applications include headers and beams, hip and valley rafters, scaffold planking and the flange material for prefabricated wood I-joists.



 LVL Specification：

Products Name	LVL I Joist Beam
Size	1220*2440mm
Thickness	5mm; 6mm; 9mm
Tolerance	± 0.1mm
Core Veneer	Poplar; Pine; Hardwood
Face Veneer	Plain
Glue Grade	MR; Phenolic



Details Display：

It possesses sufficient flexural strength, compressive strength, and elastic modulus to meet the design load requirements for use as a support or keel.



Treated with moisture-proof adhesive, it can be used in humid environments (such as foundation formwork, outdoor scaffolding steps, and areas in contact with soil) for extended service life and potential for repeated use.





Why is it necessary to form lvl timber along the grain direction?

High Strength: Tensile, compressive, and flexural strengths are significantly higher than those across the grain.

High Stiffness: Resists bending and deformation (bending along its length).

Good Nail Holding: Nails or screws hold better when driven along the grain.

Susceptibility to Splitting: Splitting is more likely to occur along the grain (i.e., along the length of the timber).

In Summary: Timber must be used along the grain in building structures (such as wall studs, floor joists, roof rafters, and beams in timber-framed buildings) and in scaffolding and formwork support systems. This is to leverage its high strength and stiffness along the grain to carry the primary compressive and bending loads.
